3000LB Viper Midnight Synthetic Rope Winch Kit For The Honda Rancher TRX420 TM**

Description

This winch kit includes everything needed to install the winch on the Honda ATV’s listed in the fitment table below.

It includes the 3000lb Viper Midnight Synthetic Rope series winch, handlebar rocker switch to control the winch, model specific winch mount, and all the necessary hardware and wiring.

This KFI Winch Kit fits the following Honda models ONLY:

Fitment:

Year

Rancher TRX420(Solid Axle ONLY) –(FA*FE*FM*TE*TM)

2014

Rancher TRX420 – (FA*FE*FM*TE*TM)

’15-23

Foreman TRX500 – (FM1E*FE1E*FM2E*FE2E*FM*FPM*FPE)

’14-19 Foreman TRX520 (All Models)

’20-23 Rubicon TRX500 4×4 (All Models)

’15-19 Rubicon TRX520 (All Models)

’20-23

Winch MountSpecifications:

• 100% MADE IN USA
• Constructed of 10 ga steel
• Mounts your winch back behind your bumper in your frame
• Unlike all other mount competitors, our mounts are metal bead blasted before they are powder coated for the best possible finish prep.
• Powder coated black for supreme durability
• Complete installation instructions included
• Plastic trimming required
• All mounting hardware included

Viper Midnight 3000lb Winch Specifications:

VIPER Midnight Series wincheshave composite housing and all metal gears. Midnight Series winches include an automatic brake standard. The automatic brake is highly recommended for anyone using their winch with a plow.

Features:

• Metal gears
• Mechanical load holding and dynamic brake
• 1 Year Warranty (winch) / 6 months (rope)
• Black Dyneema Synthetic Rope

Kit Contents:

• Synthetic Rope (rope includes 6 month warranty)
• Fairlead – Roller or Aluminum Hawse based on the type of cable
• Contactor / Solenoid & Wiring
• Rocker Handlebar Switch (LED Dash Switch Upgrade Available)
• Clevis Hook
• Universal Fairlead Mount Plate
• Installation Hardware and Instructions

Specs:

• Dyneema Synthetic Rope– 50 feet
• Dimensions:
• Midnight 3,000 : 12.25 inch (L) x 4.5 inch (W) x 4.5 inch (H)
• Motor – 12V DC, permanent magnet motor
• Brake – Mechanical load holding and dynamic
• Gearing – Steel planetary gears
• Wiring – [8 gauge (English) – 84/.3 (Metric)]
• Hardware – stainless steel
• Mounting Bolt Pattern – 3.0 inch x 4.875 inch (76mm x 123. 83mm)
